휴대형 분광계
Spectroradiometer MS-720
휴대형분광계, 분광측정기, 수평분광계, 기상관측, 태양광, 기후연구
분광 측정범위 350 – 1,050nm
MS-720 시리즈는 파장별 광 방사선량을 측정하는 장치입니다. 농업 분야, 해양 분야 및 원격 감지, 필드 (야외)에서의 사용에 최적의 휴대형 분광 복사계 입니다.
Features
- MS-720 is portable (WI00 x Dl60 x H60mm. 720g) and suitable for outdoor measurement. The operation is easy with the integrated LCD and the tact switch.
- A stable diffuser, grating spectrometer and diode-array are adopted. MS-720 is highly reliable because there are no movable parts which could affect the measurement accuracy. MS-720 software automatically deterrnines the exposure time to perform the best measurement.
- Automatically displays Irradadiance (W/m2), Luminance (lumen), PAR (µmol/m2/s)
제품특징
- 배터리 구동 휴대용 디자인으로 LCD 모니터를 탑재하고 있기 때문에 야외에서 각종 분광 분석을 쉽게 할 수 있습니다.
- 옵션 품목 GPS 장치를 연결하여 정확한 측정위치 데이터를 검색 · 저장할 수 있습니다.
- 저장된 데이터는 측정 후 PC로 전송하여 저장하거나 데이터 연산할 수 있습니다.
- 위성 항공기 원격 탐사 데이터의 각종 일반적인 분광 측정에 사용할 수 있습니다.
MS-720 portable spectroradiometer is designed to measure the spectral irradiance in the range from Visible to Near-Infrared. The MS-720 is mainly used for the data acquisition for geological features, vegetation, oceanography, remote sensing and other applications. MS-720 is a handheld sensor with an integrated LCD and an internal memory. Therefore, it is suitable for outdoors stand-alone measurements. A small-sized stable grating spectrometer with photo diode array is integrated. The data can be simply downloaded to a PC by using the MS-720 control software. Several scientific functions are incorporated (e.g calculate the integrated irradiance of a measured spectrum against a reference spectrum).
Specifications
| Specifications (typical) | MS-720 (Hardware) |
| 01) Wavelength range | 350 – 1,050nm |
| 02) Wavelength interval | 3.3nm |
| 03) Wavelength resolution | 10nm |
| 04) Wavelength accuracy | Less than 0.3nm |
| 05) Aperture angle (Full view angle) |
180° (Option: 45°, 25°, 10°) |
| 06) Stray light | Less than 0.15% |
| 07) Temperature dependency | ±5% |
| 08) Unit of the output | W/m²/µm |
| 09) Measurement time | 0.005 to 5sec/Automatic controlled time |
| 10) Maximum number of the data | 800 (Approximately 2 minutes for download) |
| 11) Power supply | AA battery x 4 Optional AC adapter DC5V |
| 12) Size | W100 x D165 x H60 (mm) |
| 13) Weight | Approx. 720g (Including batteries and Aperture) |
| 14) Communication | RS-232C/USB |
| 15) Operating temperature range and humidity | Temperature : -10 to +40 Humidity : 0 to 90%RH (no condensation) |
| Specifications | MS-720 (Software) |
| 1) Program | Analysis software : MS720_x64.exe（64bitOS） MS720_x86.exe（32bitOS） |
| 2) OS | Microsoft Windows 7/8/8.1 |
| 3) Interface | RS-232C/USB |
| 4) Functions | Display the data (List view/Detailed view) Save the data (CSV format) Analyze the data (Data comparison) |
| Specificastions | PC |
| 1) CPU | Better than Pentium 200MHZ (recommended) |
| 2) Memory | >=64MB (recommended) |
| 3) Hard disc | >=10GB (recommended) |
| 4) Screen | >=l024 x 768 (recommended) |
| 5) Others | CD-ROM drive, RS232C port, USB port |
